Brief introduction

    DLX-DVOPB Series Bi-direction video/audio/data fiber transmitter and receiver adopts ASIC and advanced digital video & fiber transmission technology, provide uncompressed high quality real time transmission for 1~64 channels of Bi-direction video, up to 32 channels of bi-directional data and audio signals, 4 channels E1/T1 and 10/100M self-adaptive Ethernet data over one single mode or multimode optic fiber.

    DLX-DVOPB Series products is free of outside environment interference. Stable working for long time. Support remote end and local end equipments been managed by SNMP software. Extremely flexible with the ability to add/drop video, audio, RS232/RS422/RS485, E1, 100M Ethernet ports via plugging in/out our field-proven service cards. Support Broadcast grade video transmission,24bits DVD format, High Dynamic Range video and Stereo audio. Auto-adapt to various audio, video and data etc signals without adjustment.

    The various types of DLX-DVOPB products can meet different user’s demands. Adopts advanced digital fiber optic transmission technologies, DVOP devices can be installed rapidly without customer adjusting, and they are easy to operate and maintain. On the front panel of the products are video connector (BNC), audio and data connector (RJ45 or Terminal Plug with screw clamps), and fiber optic connector (FC-single mode or SC-multimode). Users can easily monitor the status of power supply, connection and channels through the indicator lights. There are two types of DLX-DVOPB available: standalone and card type.

Application

● Multi-services Flexible Configuration on the Same Platform

● Indicators for Power Supply, Video, Optic-link and Data-loop

● Free from In-field Adjustment

Digitization: 24bit

Bandwidth: 20Hz to 20KHz

Nonlinear distortion coefficient: ≤1%

SNR: >85dB

Connector: RCA(unbalanced) or XLR(balanced)

● Data
